WCED 4 Way Metal Clad Garage Consumer Unit 63A RCD + 6A / 16A MCBs – WMGU04/616
Part No Description
WMGU04/616 4 Way Metal Clad Garage Consumer Unit 63A RCD + 6A / 16A MCBs
WCED metal consumer units are finished in white polyester powder coating. Multiple circular cable entry knock-outs (25 & 32mm) on top and bottom, 40mm on the sides and back plus larger rear slots.
Raised key holes for secure easy installation. Raised din rail improves cable routing. Supplied with neutral and earth terminal bars, neutral cable and pin style bar.
The WMGU04/616 is a compact IP40 metal garage consumer unit fitted with a 63 A Type A RCD incomer and twin B Curve MCBs rated at 6A and 16A. It provides safe and compliant circuit protection for garages, workshops, and outbuildings where a durable all-metal enclosure is preferred.
Key Features
- 63 A Type A RCD incomer (30 mA – AC & pulsating DC protection)
- 6 A + 16 A B Curve MCBs for lighting and light power circuits
- IP40 rated all-metal enclosure with earthed drop-down lid
- Integrated earth & neutral bars pre-wired for fast installation
- Compact footprint: 130 mm (W) × 258 mm (H) × 110 mm (D)
- Fully compliant with BS EN 61439-3 and BS 7671 Amendment 2
Dimensions (WxHxD) – 130mm x 258mm x 110mm
