Live Electrical 25A 1P+N A-Type Bi-Directional RCBO C Curve 6kA 30mA – RNC125C-030N

Live Electrical 25A 1P+N A-Type Bi-Directional RCBO C Curve 6kA 30mA

Part No                        Description

RNC125C-030N           25A 1P+N A-Type Bi-Directional RCBO C Curve 6kA 30mA

RNC is a range of MCB sized RCBOs, apply to circuit of AC50/60Hz. Rated voltage to 230V, and current up to 40 A, bring higher levels of safety to an  electrical installation and its users because they include switched neutral as standard, which will guarantee that healthy circuits remain in service and  that only a faulty circuit is switched off.

● Rated current In(A): 6,10,16,20,25,32,40
● Rated voltage Un: 240VAC
● Poles: 2P
● Trippping curve: B,C.
● Residual current operating characteristic: Type A
● Rated frequency: 50/60 Hz
● Rated short-curcuit breaking capacity Inc: 6kA.
● Operating temperature: -25~+40℃.
● Contact position degree: IP20
● Rated residual operating current lAn(mA): 10,30,100,300mA
● Complies with BS EN610009-1
● Bidirectional.
● Terminal capacity: 10mm²
● Type A
