Haydon 12V x 3.5A Inline PSU c/w 3.6m Lead and UK Plug – HAY-PSUINLINE3.5A
Part No Description
HAY-PSUINLINE3.5A 12V x 3.5A Inline PSU c/w 3.6m Lead and UK Plug
This high quality inline power supply offers 12v 3.5A, perfect for supplying power to one IR camera. Robust and reliable makes the 1 way inline PSU an industry favourite.
Input Range: 100 ~ 240 VAC
Input Frequency: 50/60Hz
Inrush Current: < 20A at 115VAC; <40Aat 230VAC, COLD STAR AT 25ºC
Input Current: 3A Max
Leakage Current: < 1.5 mA at 50/60 Hz 240VAC Input
Rated Output Power: 42 Watts
Output Voltage: 12 V±4% (11.52V ≤ V outputs ≤ 12.50V)
Output Current: 3.5A
Output Load Efficiency: ≥80% AT 240VAC full load
Adjustment Range: Fixed
Hold-up Time: 30 ms at full load and 230 VAC nominal line
OL Protection: 96% to 104% above peak rating
Ripple & Noise: ≤ 200mV at rated Load
EMI Test: EN55022 CLASS, EN6100-3-2.3, FCC CLASS B
Isolation: AC3.0 KV/1 min (input to output)
Safety Approval: CE, CCC, FCC
Operating Temp: 0ºC to 50ºC ambient derate each output at 4.0% per
degree from 50ºC to 60ºC
Storage Temp: – 40ºC to 85ºC
Operating Humidity: 5% to 95% (non-condensing)
MTBF: 100,000 hours at full load and 25ºC ambient conditions (demonstrated)
Size: 120 X 55 X 30MM
Cable Length: 3.6m
UK Plug & 2.1mm Socket: Yes
