Greenbrook 24Hr Mechanical Timer Socket Box Mount 16A – T100A

T100A               24Hr Mechanical Timer Socket Box Mount 16A

Greenbrook T100A 24 Hour Mechanical Timer 16A – Socket Box Mount

The Greenbrook T100A 24 Hour Mechanical Timer provides a simple and reliable way to automatically control electrical appliances on a daily schedule. Rated at 16A, it is particularly suitable for heating applications, including immersion heaters up to 3kW.

Featuring a traditional mechanical dial with 96 ON/OFF settings and a minimum switching interval of 15 minutes, the T100A allows appliances to be programmed throughout a 24-hour period. An ON / Timed / OFF selector also provides convenient manual override when required.

Designed for a neat flush-mounted installation, the timer fits directly onto a 35mm deep socket box with an earth terminal. It can also be installed in a 35mm dual appliance socket box, making it ideal for positioning alongside a fused spur or socket outlet. A built-in Timer ON status indicator provides a clear visual indication when the connected appliance is operating.

Key Features

• 24-hour mechanical timer for automatic daily control
• 16A maximum load
• Suitable for immersion heaters up to 3kW
• 96 ON/OFF settings
• 15-minute minimum switching time
• ON / Timed / OFF manual override selector
• Timer ON status indicator
• Fits a standard 35mm deep socket box
• Suitable for use with a 35mm dual appliance socket box
• Single channel
• White matt polycarbonate construction
• IP20 rated
• Operating temperature: -10°C to +55°C
• 1-year Greenbrook guarantee
• CE and UKCA compliant

Technical Specification
