GARO GEV7.4 Smart 7.4kW Socketed Type 2 EV Charger – GEV7.4O
Part No Description
GEV7.4O GEV7.4 Smart 7.4kW Socketed Type 2 EV Charger
The GARO GEV7.4O Smart 7.4kW Socketed Type 2 EV Charger is a premium single-phase home EV charger designed for residential installations. It combines smart charging functionality, integrated safety features, and dynamic energy management, making it suitable for both standard home charging and solar-assisted installations.
Product Overview
The GARO GEV7.4O delivers up to 7.4kW (32A) charging via a Type 2 socket, allowing you to use your own charging cable. With built-in Wi-Fi and Ethernet connectivity, it supports app control, OCPP 1.6 compatibility, RFID authentication, dynamic load balancing and solar energy integration. It also includes comprehensive electrical protection such as PEN fault detection, AC/DC residual current protection, and over/under voltage monitoring.
Key Features
- 7.4kW single-phase EV charger
- Untethered Type 2 socket
- Maximum 32A charging current (adjustable 6–32A)
- Wi-Fi & Ethernet connectivity
- Smart App control
- OCPP 1.6 compatible
- RFID user authentication
- Dynamic Load Management (CT clamp supplied)
- Solar Energy Load Management
- Integrated energy metering
- Built-in PEN fault protection
- 30mA Type A + 6mA DC leakage protection
- Over current, over/under voltage & over-temperature protection
- IP54 weatherproof enclosure
- Wall mounted
- CE & UKCA approved
- Compliant with EN 61851-1 & IEC 61439-7 standards
Technical Specification
| Specification | Details |
|---|---|
| Model | GEV7.4O |
| Charging Power | 7.4kW |
| Supply Voltage | 220–240V AC |
| Current | Up to 32A (Adjustable) |
| Connector | Type 2 Socket |
| Charging Mode | Mode 3 |
| Frequency | 50/60Hz |
| Communication | Wi-Fi, Ethernet |
| Protocol | OCPP 1.6 |
| RFID | Yes |
| Load Management | Yes |
| Solar Integration | Yes |
| Metering | Integrated |
| Protection | AC30mA + DC6mA, PEN Fault, Over Current, Voltage & Temperature Protection |
| IP Rating | IP54 |
| Operating Temperature | -25°C to +40°C |
| Weight | 4.2kg |
| Dimensions | 330 × 200 × 121mm |
