Garo Diamond 32 Way Dual Row Metal Clad Consumer Unit 100A Isolator SPD 27 Free Ways – GS32S27C
Part No Description
GS32S27C Diamond 32 Way Dual Row Metal Clad Consumer Unit 100A Isolator SPD 27 Free Ways
Exclusive design for surface mounting. The housing is manufactured in metal and is also fitted with a door. Each unit is supplied with earth and neutral blocks, additional blocks can be fitted on request.
The enclosures are manufactured from steel. Applicable standard is EN61439-3 for a rated current 100A at 230 Volts.
All Garo consumer units are assembled in our manufacturing facility specialising in quick turnaround on bespoke orders.
Amendment 3 compliant.
Full CAD design service available.
Key Features
Space-Savings: Houses more circuits in a compact unit.
Higher Circuit Capacity: Ideal for installations needing multiple circuits.
Simplified Installation: Reduces need for multiple units and saves on labour.
Better Cable Management: Minimises excessive cabling.
Cost-Effective: Fewer materials and labour required.
Future-Proofing: Room for future circuit additions in the same unit.
Easy Maintenance: Centralised circuits simplify troubleshooting and repairs.
Technical data
Rated current: 100A
Rated voltage: 230 V AC
Frequency: 50/60 Hz
Rated short-circuit capacity: 4 kA
Main Device: Double Pole Isolator 100A
Additional Devices None
Surge Protection: Type 11 ( TNC, TNS)
Degree of protection: IP40
Total number of ways: 32
Total Number of free ways: 27
Height..mm (H): 520
Width..mm (W): 364
Depth..mm (D): 118
Ambient temperature (C): -25…..+55
Storage temperature (C): -35…..+55
Terminals: 35mm
Maximum Backup Protection (A): 100
Standard: EN 61439-3
Compliance with: BS 7671
Dimensions
32 Way – W 364 x H 520 x D 118mm
