Garo 100A 3 Pole Metal Clad Switch Fuse IP65 – GSF3100N

Specification

Rated insulation voltage Ui (V): 1000
Rated thermal current, Ith (A) 1): 100
Rated operational current Ie (A): AC-21 400/415V – 100
AC-22 400/415V – 100
Rated operational power (kW): AC-23 400/415V – 30
Rated fused short circuit current: Max. Back-up fuse (A) – 100
R.M.S. value Ik (kA) – 50
Impulse withstand voltage Uimp (kV): 8
Electrical endurance (operations): 2000
Mechanical endurance (operations): 20000
Terminals / Bolt size Cu (mm²): 2.5-35
Max terminal torque (Nm): 2.2
